For sale is ONE (1) used Tektronix multi-format monitor. Excellent condition. Tested & 100% functional. It has many options HD, EYE and PHY included. Front panel was upgraded. Actual photos are showed.
The HD-capable Tektronix WFM7100 offers high performance monitoring and measurement for applications involving HD digital video. It combines the video and audio monitoring capabilities available on the WFM7020 in-depth data analysis (Opt. DAT), and SDI signal measurement.
- Option SD: Adds support for standard definition (SD) serial digital monitoring; two SD-SDI inputs. Standard for all listed instruments.
- Option HD: Adds support for high definition (HD) serial digital monitoring; two HD-SDI inputs.
- Option EYE: Adds Eye pattern display, cable length and Jitter measurements
- Option DAT: Adds data analysis and ANC Data Inspector capabilities. Allows for logic-level view of video and embedded audio data stream and ANC data extraction
- Option DS: Digital Audio
- Option PHY: Adds Option EYE capabilities plus automated Eye parameters measurement and Jitter waveform display
